NZXT H1 Mini-ITX With 140mm AIO Liquid Cooler and SFX-L 650W 80 Plus Gold

The H1 is a small form factor case without the hassle, with pre-routed cables and an integrated PSU, AIO, and PCIe Gen3 Riser cable.

Compact vertical design with support for most full-sized GPU’s on the market
Toolless SSD tray and riser card for simple installation
Pre-routed cables and downward-facing motherboard I/O faces down route all cables through the bottom of the case
Integrated power supply, AIO liquid with pre-routed cables
Integrated PCIe Riser card included for vertical GPU mounting
Dual-chamber airflow

Disponibilité : Disponible

2 490 MAD
~~2 999 MAD~~

Bienvenue chez EliteGear, le leader du PC gamer au Maroc ! Nous sommes dédiés à offrir des ordinateurs de haute performance, conçus pour repousser les limites du gaming.

Commandez ici

Description

The H1 is a small form factor case without the hassle, with pre-routed cables and an integrated PSU, AIO, and PCIe Gen3 Riser cable.

Compact vertical design with support for most full-sized GPU’s on the market
Toolless SSD tray and riser card for simple installation
Pre-routed cables and downward-facing motherboard I/O faces down route all cables through the bottom of the case
Integrated power supply, AIO liquid with pre-routed cables
Integrated PCIe Riser card included for vertical GPU mounting
Dual-chamber airflow
Inside the Box

- H1 Case1
- 140mm AIO Liquid Cooler1
- SFX-L 650W 80 Plus Gold Power Supply1
- Aer P140mm Fan1
- PCIe 16x Gen3 High-Speed Riser Card1
- Breakout Cable1
- Installation Accessories1
- Manual
- Tech Specs
  Dimensions
  - Height:388mm / 15.28 inches
  - Width:187mm / 7.36 inches
  - Depth:188mm / 7.4 inches
  - Weight:6.53 kg / 14.4 lb
  Compatibility & Clearance
  - Max GPU Clearance:305 x 128mm – 265 x 145mm
  - Max GPU Thickness:Up to 2.5 Slots
  - Memory Height:45mm
  Front I/O Ports
  - USB 3.2 Gen 1 Type-A:1
  - USB 3.2 Gen 2 Type-C:1
  - Headset Audio Jack:1
  Expansion Slots
  - Standard:2
  Drive Bays
  - 2.5″:2
  - 3.5″:–
  Pump
  - Dimensions:65 x 65 x 27mm
  - Motor Speed:4,200 ± 420RPM
  - Power:12V DC, 0.3A
  - Connector:3-pin
  Radiator
  - Dimensions:139 x 174 x 22mm
  - Material:Aluminum
  Compatible Socket & CPU
  - Intel:Socket LGA 1200, 115X
  - AMD:AMD Socket AM4, FM2+, FM2, AM1, AM3+, AM3, AM2
  Fan Specs
  - Model:Aer P 140mm
  - Speed:500 – 1,800 ± 300RPM
  - Airflow:27.27 – 98.17 CFM
  - Static Pressure:0.21 – 2.71 mm-H₂O
  - Noise:21 – 38 dBA
  - Fan Connector:4-pin PWM
  Power Supply Specs
  - Model:NP-S650M
  - Form Factor:SFX-L
  - Modular:Full
  - Wattage:650W
  - Compliance Standard:SFX 12V V.3.3 / ATX 12V V.2.4 compatible with Intel V.1.31
  - Energy Efficiency:80 Plus Gold 20% loading: 87%, 50% loading: 90%, 100% loading: 87% @115Vac
  - Fan:120mm FDB Fan
  - MTBF:100,000 hours at 25°C. excluding the DC Fan.
  - Protection:OPP, OVP, UVP, OCP, OTP, SCP
    PCIe Extender Cable

    Form Factor:X16

    Compatibility:PCI-E 3.0 Passed

    Cable Length:315mm
    General

    Warranty:3 years on case and riser card – AIO 10 years on PSU

    Model Number:CA-H16WR-W1 / CA-H16WR-B1
